Disc Crusher
The disc crusher directly feeds the material into the rotary cutter to crush the material. The machine cuts the material by rotating the blade. It has high output, the material is directly cut, the machine performance is stable, and the output is based on user requirements.
| PRODUCT MODEL MOLD |
||||||
| MODEL | YIELD(T) | POWER(KW) | Number Of Blades | Disc Diameter | PACKAGE SIZE (MM) |
WEIGHT (T) |
| 2000 | 1-2 | 30-45KW | 38 pieces | 1400mm | 3800×2000×2550 | 2.2 |
| 2400 | 2-4 | 55-75KW | 56 pieces | 1800mm | 4200×2400×2700 | 3.4 |
| 2600 | 2-5 | 75-90KW | 56 pieces | 1800mm | 4200×2600×2850 | 3.8 |
| 2800 | 3-6 | 90-110KW | 68 pieces | 2000mm | 4500×2800×2850 | 4.8 |
| 3000 | 4-7 | 110-132KW | 80 pieces | 2200mm | 4700×3000×2850 | 5.6 |
| 3200 | 5-8 | 132-160KW | 92 pieces | 2400mm | 4800×3200×3000 | 6.4 |
| 3600 | 6-10 | 132×2KW | 104 pieces | 2600mm | 4800×3600×3200 | 7.6 |
Key Points
1.The turntable can store a large amount of materials and realize non-intermittent crushing.
2.High crushing efficiency and strong crushing intensity.
3.Bundle crushing saves more human resources.
PRODUCT STRUCTURE
Customer visit
FAQ
1.What is your minimum order quantity, can you send me samples?
Our minimum quantity is 1 set, as our product is machinery equipment, it’s difficult to send you samples, however,we can send you catalog, warmly welcome you to come visit our company
2.What is the delivery time of your machine?
In general, the delivery time of our machine is about 30 days, customized machine will be delivered as the negotiation with our clients.
3.Can the machine be customized as our need, such as put on our logo?
Surely our machine can be customized as your need, Put on your logo is also available.
4.About the after-sale service, how can you solve the problems occurred of your overseas customer in time?
The warranty of our machine is normally 12 months, during this period, we will arrange the international express immediately, to make sure the replace parts to be delivered as soon as possible.
5.After we placing an order, will you arrange the installation of the machine at present?
All the machines will be tested well before delivered, so almost of them can be used directly, also our machine are easy to be installed, if you customer needs our assistance, we will be pleased to arrange the installation, but all the cost will be charged by you.
6.What service can we provide?
We have 24hrs on line technical service The delivery service around the world And on site technical service for the full set crushers Accepted Delivery Terms: FOB；FCA,CIF,CFR Accepted Payment Currency:RMB or US dollar, etc; Accepted Payment Type: T/T,LC Language Spoken:Accept all
